Generic LoRa device (programmable)

PreviousGeneric LoRa device (preset connectivity)NextGeneric M2M device

Last updated 3 months ago

Was this helpful?

Generic LoRa device (programmable)

Connect a LoRa device for which you currently do not have LoRa connectivity credentials (DevEUI, AppEUI, and AppKey). These credentials will be provided during registration of the device in KPN Things.

  • Supported network type(s): KPNLORA

  • Device Specification ID: own-lora

  • Device Specification UUID: 1e7f596c-6eb4-44d2-bec6-0d93181d4330

Decoders
decoderSpecificationUUID
Description

+ LoRa Geolocation data

aa2a1fa0-2613-4309-9ed6-72de96047d7d

= Raw LoRa payload

6da609d1-0ec4-4f07-89e6-2acad60b7cdf

Forward the raw LoRa payload and port number without decoding.

= Raw LoRa payload (v2)

1c0f77b0-2947-5e08-a5a8-d311cb094c3c

Forward the raw LoRa payload and port number without decoding.

= Raw LoRa payload Extended

f087f4f5-f603-47d3-be94-790e99b150cf

Forward the raw LoRa payload and lora network metadata without decoding.

= Raw LoRa payload Extended (v2)

71910f65-a9d6-587e-9148-c01ec440fdd2

Forward the raw LoRa payload and lora network metadata without decoding.

› Decoded ThingsML for LoRa payload

bdf13a5d-95f2-4595-baf0-cd807ff796b1

› Decoded ThingsML for LoRa payload (v2)

174b8034-70c9-545a-9dfc-2e8353c5301d

Encoders
encoderSpecificationUUID
Description

= Raw LoRa payload

30fdeedd-69e6-4ab5-8a90-2d58af7b3b2f

Send raw LoRa payload to your device.

+ LoRa Geolocation data

= Raw LoRa payload

Forward the raw LoRa payload and port number without decoding.

Expected SenML records

name
type
unit

payload

string

port

number

= Raw LoRa payload (v2)

Forward the raw LoRa payload and port number without decoding.

The following SenML records can be present, amongst others:

name
type
unit
example
description

payload

string

"4D985C495AC4D8C9682CFD"

The LoRa hex payload

port

number

200

The LoRa port used to send this uplink

Example SenML

[
    {
        "bn": "urn:dev:DEVEUI:0123456789012345:",
        "bt": 1693136532.83,
        "n": "payload",
        "vs": "4D985C495AC4D8C9682CFD"
    },
    {
        "n": "port",
        "v": 1
    },
    {
        "n": "timeOrigin",
        "vs": "NETWORK"
    }
]

= Raw LoRa payload Extended

Forward the raw LoRa payload and lora network metadata without decoding.

Expected SenML records

name
type
unit

ADRbit

number

Channel

string

DevLrrCnt

number

FCntDn

number

FCntUp

number

LrrESP

string

LrrRSSI

string

LrrSNR

string

SpFact

number

SubBand

string

payload

string

port

number

Raw LoRa payload Extended (v2)

Forward the raw LoRa payload and lora network metadata without decoding.

Fixes from '= Raw LoRa payload Extended':

  • LrrRSSI is changed to a number.

  • LrrSNR is changed to a number.

  • LrrESP is changed to a number.

The following SenML records can be present, amongst others:

name
type
unit
example
description

ADRbit

number

0

Adaptive Data Rate indicator

Channel

string

LC255

Lora channel of the transmission

DevLrrCnt

number

0

Amount of gateways that received the message

FCntDn

number

21725

The downlink framecounter

FCntUp

number

30117

The uplink framecounter

LrrRSSI

number

0

Received Signal Strength Indicator

LrrSNR

number

0

Signal to Noise Ratio

payload

string

"4D985C495AC4D8C9682CFD"

raw hex payload string

port

number

1

LoRa port used

SpFact

number

9

Spreading factor used

SubBand

string

"G0"

Lora band of the transmission

Example SenML

[
    {
        "bn": "urn:dev:DEVEUI:0123456789012345:",
        "bt": 1693136532.83,
        "n": "payload",
        "vs": "8ca683bd93124178afc5ff"
    },
    {
        "n": "port",
        "v": 1
    },
    {
        "n": "FCntUp",
        "v": 30117
    },
    {
        "n": "FCntDn",
        "v": 21725
    },
    {
        "n": "LrrRSSI",
        "v": 0
    },
    {
        "n": "LrrSNR",
        "v": 0
    },
    {
        "n": "DevLrrCnt",
        "v": 0
    },
    {
        "n": "SpFact",
        "v": 9
    },
    {
        "n": "SubBand",
        "vs": "G0"
    },
    {
        "n": "Channel",
        "vs": "LC255"
    },
    {
        "n": "ADRbit",
        "v": 0
    },
    {
        "n": "timeOrigin",
        "vs": "NETWORK"
    }
]

› Decoded ThingsML for LoRa payload

› Decoded ThingsML for LoRa payload (v2)

Example SenML

The resulting SenML completely depends on the ThingsML input and can produce almost any type of SenML output. The decoded ThingsML provided below is just an illustration of what is possible.

[
    {
        "bn": "urn:dev:DEVEUI:6E5E267F2E6FB3BF:",
        "bt": 1693136532.83,
        "n": "latitude",
        "u": "lat",
        "v": 51.90717
    },
    {
        "n": "longitude",
        "u": "lon",
        "v": 4.48940
    },
    {
        "n": "temperature",
        "u": "Cel",
        "v": 29.75
    },
    {
        "n": "batteryVoltage",
        "u": "V",
        "v": 3.59
    },
    {
        "n": "extTemp",
        "u": "Cel",
        "v": 17.22
    },
    {
        "n": "io",
        "vb": false
    }
]

= Raw LoRa payload encoding

  • Protocol: LoRa downlink

  • Description: Send raw LoRa payload to your device.

  • Multiple commands in one downlink: No

Input mapping:

  • Name: payloadHex (raw input)

Add data to messages where location could be calculated.

Decoder for , a generic LoRa payload protocol by KPN.

Decoder for , a generic LoRa payload protocol by KPN.

Add data to messages where location could be calculated.

This decoder also decodes data.

SenML can be structured in different ways, and we do not guarantee the examples below will look the same as what you will receive on your Destination. To make sure you can handle the SenML optimally, take a look at our documentation about .

This decoder also decodes data.

SenML can be structured in different ways, and we do not guarantee the examples below will look the same as what you will receive on your Destination. To make sure you can handle the SenML optimally, take a look at our documentation about .

Decoder for , a generic LoRa payload protocol by KPN.

Decoder for , a generic LoRa payload protocol by KPN.

This decoder also decodes data.

SenML can be structured in different ways, and we do not guarantee the examples below will look the same as what you will receive on your Destination. To make sure you can handle the SenML optimally, take a look at our documentation about .
