Device Simulator (Mobile Phone app)

A device specification for the Things Device phone App.

  • Supported network type(s): INTERNET

  • Device Specification ID: own-phone-qr

  • Device Specification UUID: 3f77934a-2310-4504-89d7-08f40a25c2b8

Decoders
decoderSpecificationUUID
Description

› Decoded ThingsML and raw SenML data

55e10f0f-23e6-40c3-a1f0-1e468f9cca1c

One decoder to forward raw SenML data and decoded ThingsML data sent by the device.

› Decoded ThingsML and raw SenML data (v2)

9bbb7980-b08b-5902-8d10-1fe68f2c64f7

Decoder that forwards raw SenML data and decoded ThingsML data sent by the device.

Encoders
encoderSpecificationUUID
Description

= SenML data

e83cf205-3ef5-44c3-979a-fa7dd3e132c8

Send SenML data to your device.

› Decoded ThingsML and raw SenML data

  • UUID: 55e10f0f-23e6-40c3-a1f0-1e468f9cca1c

  • Description: One decoder to forward raw SenML data and decoded ThingsML data sent by the device.

  • Exchange: decoder.thingsml.json.exchange

Expected SenML outputs

Unknown

› Decoded ThingsML and raw SenML data (v2)

Decoder that forwards raw SenML data and decoded ThingsML data sent by the device.

Example SenML

Example SenML

This is completely dependent on the SenML or ThingsML input and could output almost any SenML. The decoded ThingsML below is just illustrative of what is possible.

[
    {
        "bn": "urn:dev:DEVEUI:fe782a953c642aeb:",
        "bt": 1693136532.83,
        "n": "latitude",
        "u": "lat",
        "v": 51.90717
    },
    {
        "n": "longitude",
        "u": "lon",
        "v": 4.48940
    },
    {
        "n": "temperature",
        "u": "Cel",
        "v": 29.75
    },
    {
        "n": "batteryVoltage",
        "u": "V",
        "v": 3.59
    },
    {
        "n": "extTemp",
        "u": "Cel",
        "v": 17.22
    },
    {
        "n": "io",
        "vb": false
    }
]

= SenML data encoding

  • Protocol: HTTP response

  • Description: Send SenML data to your device.

  • Multiple commands in one downlink: No

  • No input mapping

This decoder also decodes data.

SenML can be structured in different ways, and we do not guarantee the examples below will look the same as what you will receive on your Destination. To make sure you can handle the SenML optimally, take a look at our documentation about .
