  1. BUILDING BLOCKS
  2. Devices
  3. Sensors

Generic M2M device (with Internet connection)

PreviousGeneric M2M deviceNextTrackers

Last updated 3 months ago

Was this helpful?

Generic M2M device (with Internet connection)

Connect your own M2M Device that communicates over the Internet. Useful when only Device management data is sent to KPN Things. Part of the Device Management + Connectivity only proposition.

  • Supported network type(s): MQTT,INTERNET,KPNM2M

  • Device Specification ID: own-m2m-with-internet

  • Device Specification UUID: cf872c9e-9343-47db-b972-35dc4df340c8

Decoders
decoderSpecificationUUID
Description

› Decoded ThingsML and raw SenML data

c876bac7-c664-4297-a954-2666eb6aae54

One decoder to forward raw SenML data and decoded ThingsML data sent by the device.

› Decoded ThingsML and raw SenML data (v2)

45b27e02-8136-540b-a4e1-509d7a2c2aa2

Decoder that forwards raw SenML data and decoded ThingsML data sent by the device.

Encoders
encoderSpecificationUUID
Description

= SenML data

cc35ab44-01d3-4086-885a-a30cb37c0a12

Send SenML data to your device.

› Decoded ThingsML and raw SenML data

  • UUID: c876bac7-c664-4297-a954-2666eb6aae54

  • Description: One decoder to forward raw SenML data and decoded ThingsML data sent by the device.

  • Exchange: decoder.thingsml.json.exchange

Expected SenML outputs

Unknown

› Decoded ThingsML and raw SenML data (v2)

Decoder that forwards raw SenML data and decoded ThingsML data sent by the device.

Example SenML

This is completely dependent on the SenML or ThingsML input and could output almost any SenML. The decoded ThingsML below is just illustrative of what is possible.

[
    {
        "bn": "urn:dev:DEVEUI:fe782a953c642aeb:",
        "bt": 1693136532.83,
        "n": "latitude",
        "u": "lat",
        "v": 51.90717
    },
    {
        "n": "longitude",
        "u": "lon",
        "v": 4.48940
    },
    {
        "n": "temperature",
        "u": "Cel",
        "v": 29.75
    },
    {
        "n": "batteryVoltage",
        "u": "V",
        "v": 3.59
    },
    {
        "n": "extTemp",
        "u": "Cel",
        "v": 17.22
    },
    {
        "n": "io",
        "vb": false
    }
]

= SenML data encoding

  • Protocol: HTTP response

  • Description: Send SenML data to your device.

  • Multiple commands in one downlink: No

  • No input mapping
