Generic Device (Internet connected)

Generic Device (Internet connected)

Connect your (virtual) Internet-connected device to KPN Things.

• Supported network type(s): INTERNET

• Device Specification ID: own-internet

• Device Specification UUID: b2c5c303-4f74-4b58-95f5-b80455fdafbc

Decoders	decoderSpecificationUUID	Description
› Decoded ThingsML and raw SenML data	16799a1c-9dea-4fc9-83b1-03d4562aba69	One decoder to forward raw SenML data and decoded ThingsML data sent by the device.
› Decoded ThingsML and raw SenML data (v2)	4a8f1ec7-df52-5a57-a281-422e000d3b1d	Decoder that forwards raw SenML data and decoded ThingsML data sent by the device.

Encoders	encoderSpecificationUUID	Description
= SenML data	86805e45-c394-4ebc-a2e1-a47079a57999	Send SenML data to your device.

› Decoded ThingsML and raw SenML data

• UUID: 16799a1c-9dea-4fc9-83b1-03d4562aba69

• Description: One decoder to forward raw SenML data and decoded ThingsML data sent by the device.

• Exchange: decoder.thingsml.json.exchange

Expected SenML outputs

Unknown

› Decoded ThingsML and raw SenML data (v2)

Decoder that forwards raw SenML data and decoded ThingsML data sent by the device.

Example SenML

This is completely dependent on the SenML or ThingsML input and could output almost any SenML. The decoded ThingsML below is just illustrative of what is possible.

[
    {
        "bn": "urn:dev:DEVEUI:fe782a953c642aeb:",
        "bt": 1693136532.83,
        "n": "latitude",
        "u": "lat",
        "v": 51.90717
    },
    {
        "n": "longitude",
        "u": "lon",
        "v": 4.48940
    },
    {
        "n": "temperature",
        "u": "Cel",
        "v": 29.75
    },
    {
        "n": "batteryVoltage",
        "u": "V",
        "v": 3.59
    },
    {
        "n": "extTemp",
        "u": "Cel",
        "v": 17.22
    },
    {
        "n": "io",
        "vb": false
    }
]

= SenML data encoding

• Protocol: HTTP response

• Description: Send SenML data to your device.

• Multiple commands in one downlink: No

• No input mapping
